C30 CNC Lathe with Automatic Loading and Unloading
The C30 is a CNC lathe with an in-machine two-axis gantry robot and integrated infeed and outfeed conveyors for automatic workpiece handling. It features a one-piece cast bed, horizontal gang-tool layout, and a maximum spindle speed of 6,000 rpm.
- MOQ: 1 set
- Brand: SIPENG CNC — Tianjin, China
- Configuration: Tooling / bar feeder / parts collection / automation
- Quotation: reply within 24 hours
Specifications
| Controller | Mitsubishi E80 / M80 (optional) |
|---|---|
| Spindle nose | A2-4 |
| Spindle power | 5.5 kW |
| Maximum spindle speed | 6,000 rpm |
| Spindle center height above X-axis slide center | 60 mm |
| X-axis travel | 320 mm |
| Z-axis travel | 280 mm |
| Max. diameter for automatic loading/unloading | 85 mm |
| Max. length for automatic loading/unloading | 60 mm |
| Max. bar-stock diameter | 35 mm |
| Max. workpiece weight | 0.5 kg |
| Robot unloading cycle | 8 s; robot unloading only, not the complete machining cycle |
| Electrical supply | 3-phase, AC 380 V, 50 Hz, 8 kVA |
| Compressed air | 0.5-0.7 MPa |
| Total machine weight, standard configuration | 2,200 kg |
Product Details
C30 CNC Lathe with Automatic Loading and Unloading
Machine Overview
The C30 is a CNC lathe configured for automatic workpiece loading and unloading. The machine includes a two-axis gantry robot installed inside the enclosure, with integrated infeed and outfeed conveyors. Its design features a one-piece cast bed, a horizontal gang-tool layout, and a sheet-metal enclosure with internal splash protection.
Automatic Workpiece Handling
- In-machine two-axis gantry robot
- Integrated infeed and outfeed conveyors
- Maximum workpiece diameter for automatic loading/unloading: 85 mm
- Maximum workpiece length for automatic loading/unloading: 60 mm
- Maximum bar-stock diameter: 35 mm
- Maximum workpiece weight: 0.5 kg
- In-process measurement: optional
- Automatic workpiece flipping: optional
Technical Specifications
| Controller | Mitsubishi E80 / M80 (optional) |
|---|---|
| Spindle nose | A2-4 |
| Spindle power | 5.5 kW |
| Maximum spindle speed | 6,000 rpm |
| Spindle center height above X-axis slide center | 60 mm |
| X-axis travel | 320 mm |
| Z-axis travel | 280 mm |
| Total machine weight, standard configuration | 2,200 kg |
Coolant and Monitoring
- Low-pressure coolant: multi-stage centrifugal pump
- High-pressure coolant: four outlets with bag-filter filtration
- Coolant-level monitoring: low-level sensor
- Oil-mist collector: optional
Installation Requirements
- Electrical supply: 3-phase, AC 380 V, 50 Hz, 8 kVA
- Compressed air: 0.5-0.7 MPa
Robot unloading cycle: 8 seconds, as stated in the supplied document. This is the robot unloading cycle, not the complete machining cycle. Actual cycle time depends on the workpiece, process, and machine configuration.
Optional equipment and machine configuration should be confirmed for the intended application.
Interested in this product?
Send your requirement and quantity — we reply with price, lead time and technical advice within 24 hours.
Related Products
Frequently Asked Questions
I can provide drawings, material and blank specifications. Can you recommend the right machine and machining route?
Yes — that is exactly how we start. Send the drawing (PDF, DWG or STEP), material grade, blank dimensions, key tolerances and your target output. Our engineers review the part geometry and process, then recommend a machine model, fixture concept and machining route, together with an estimated cycle time. We reply with a written evaluation and quotation within 24 hours.
Can my part be completed in one setup? Which operations would need other equipment?
It depends on geometry, size and accuracy, so we answer this per part, not in general. After reviewing your drawing we reply in writing: which operations are completed in one clamping, which need a second operation or a different machine, and what the recommended process chain looks like. If a part genuinely needs two setups, we say so instead of promising one-setup results.
Are cutting tools, fixtures, bar feeder and CNC programs included?
They can all be included — the delivery scope is defined line by line in our quotation. A typical turnkey package covers the machine, fixtures designed for your parts, the tooling package, bar feeder integration and CAM programs for your parts, plus a recommended consumables list. If you prefer machine only, or want to keep your existing tooling, the scope is adjusted and every included and excluded item is listed before you sign.
How do you evaluate the machining time for my parts?
We build the process route first, then calculate cycle time from tool paths and cutting data, and cross-check it with CAM simulation. The estimated time per part is stated in the proposal. During trial cutting the actual cycle time is measured; the measured result — not the paper estimate — is the basis for acceptance, so the number you plan production around is a verified one.
Can you run trial cutting with my own material?
Yes, and we recommend it. You send material or blanks; after the machine, fixtures and programs are ready we machine your parts, record cutting parameters, cycle time and tool behaviour, and provide a trial report with measurement results, photos and video. The trial schedule is agreed with you in advance, so you can attend in person or follow it remotely.
